HANS GS-HC03 Gear Laser Welding Equipment Welding Speed 1.5 ~ 3.0M / Min

China HANS GS-HC03 Gear Laser Welding Equipment Welding Speed 1.5 ~ 3.0M / Min supplier
HANS GS-HC03 Gear Laser Welding Equipment Welding Speed 1.5 ~ 3.0M / Min supplier HANS GS-HC03 Gear Laser Welding Equipment Welding Speed 1.5 ~ 3.0M / Min supplier

Large Image :  HANS GS-HC03 Gear Laser Welding Equipment Welding Speed 1.5 ~ 3.0M / Min

Product Details:

Place of Origin: China
Brand Name: HAN’S GS
Certification: CE / TUV / ISO9001
Model Number: GS-DC030

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotation
Packaging Details: Wooden case for export
Delivery Time: 45 working days after received your payment
Payment Terms: T/T
Supply Ability: 3,000 sets per year
Contact Now
Detailed Product Description
Product Name: Laser Welding Machine Medium Of Laser: CO2/Fiber
Inner Diameter: Φ20 ~ Φ70mm Continuous Working Time: 24 Hours
Welding Speed: 1.5 - 3.0 M/min Standard: CE/TUV/ISO9001

HANS GS-HC03 Gear Laser Welding Equipment Welding Speed 1.5 ~ 3.0M / Min

Features of the robot laser welding equipment
1, A wide range of materials can be welded. Carbon steel, stainless steel, aluminum and other metals can be welded.
2, three-dimensional welding robot software can be equiped, can achieve 3-dimensional welding.
3, A wide range of applications. Aerospace, locomotive manufacturing, engineering machinery, textile machinery, agricultural machinery, elevator manufacturing, automobile manufacturing, electrical hardware manufacturing, IT and other industries.
4, Low consumption. 4000W laser source consumes about 15 degrees / hour. Protection lens 0.5-1.0 yuan / hour.
5, High welding speed, high efficiency, safe operation and stable performance.
6, Provide smooth, beautiful welding appearance without deformation.

Specification

Power Power rating 3000W
Power dynamic range 300-3000W(Adjustable)
Power stabilit <±2%
Light beam Beam mode Fundamental mode (00 mode)
Divergence angle <0.15 mrad (Full-shaped)
Beam diameter 20mm-25mm( <10m)
Directivity stability <0.2 mrad
Polarized light 45º or vertical polarization
Pulse Super intensity pulse 8-5000Hz
Pulse width 26μs—Continuous Wave
oblique wave generator 8-5000Hz
Gas Laser gas He,N2,CO2
Laser gas consumption Total≤0.2L/per hour
Electric quantity Max Power consumption 45KVA(380V,50Hz)
Cooling liquid Heat load 39KW(environmental temp 40ºC)
Coolant temperature 20ºC
Coolant temperature stability Max±1ºC
Coolant flow Min 42L/per minute
Inlet pressure Min 5.7bar, Max 10bar
In and out water pressure 5bar(When the Min flow)
Environment Temp Environmental temp 0-40ºC
Relative humidity <85%



Technical parameter of fiber laser welding



welding depth(mm) 0.5 0.8 1 1 1 2 2 2 3 3 3 4 4 5
welding power(k w) 0.5 0.5 1 1.5 2 2 2.5 3 2 2.5 3 2.5 3 3
welding speed(m/min) 0.8 0.5 1.3 2.5 4.5 2 3 3.2 1.6 2 2.4 2 2.4 1
Note: After welding of stainless steel material ,welding seam the mechanics indexes are reaching or higher than the parent material properties, and the weld forming looks good, no macroscopic defects porosity, cracks appear



Processing technology parameters and requirements:

1, the maximum welding depth: 5mm
2, the minimum weld width: 1mm
3, welding speed: 1.5 ~ 3.0M / Min
Laser welding application

Laser welding is mainly used in automobile, tools, home appliance, steel industry and others, for example nest gear of transmission,flying wheel,airbag,rock arm,muffler, silicon oil shock absorber, hydraulic torque converter, wood saw blade, diamond saw blade, radiator of water.

Our service:

After-Sale Service

1.Our after-sale network is all over the world which will provide the comprehensive after-sale service to our customer.
2.Our commitment is as follow:
3.One year guarantee for the whole equipment.
4.We will answer your questions within 24hours.
5.When Equipment warranty expires, lifelong maintenance services will be provided.
6.After the expiry of the warranty we will offer a wide range of software support with free upgrade for lifelong
